        OmniVision OV8856 MIPI Interface Fixed Focus 8MP Camera Module
        Model No.  KLT-G1K-OV8856 V2.1


   Camera Module No. KLT-G1K-OV8856 V2.1
   Image Sensor OV8856
   EFL 2.93 mm
   F.NO 2.0
   Pixel 3264 x 2448
   View Angle 75°
   Lens Type 1/4 inch
   Lens Dimensions 6.5 x 6.5 x 4.62 mm
   Module Size 14.05 x 7.80 mm
   Module Type Fixed Focus
   Interface MIPI
   Mating Connector FH26-25S-0.3SHW(05)
