OmniVision OS08A20 MIPI Interface Fixed Focus 8MP M12 Camera Module

Model No. KLT-H3MF-OS08A20 V1.0

	Camera Module No.	KLT-H3MF-OS08A20 V1.0
	Image Sensor	OS08A20
	EFL	4 mm
	F.NO	2.0
	Pixel	3840 x 2160
	View Angle	135°(D) 110°(H) 72°(V)
	Lens Type	1/1.8 inch
	Lens Dimensions	16.50 x 16.50 x 23.82 mm
	Module Size	40.00 x 22.00 mm
	Module Type	Fixed Focus
	Interface	MIPI
	Mating Connector	AXE540124
