        OmniVision OV9732 USB Interface Fixed Focus 1MP Camera Module
        Model No.   KLT-USB1A-OV9732 V1.0


 Camera Module No. KLT-USB1A-OV9732 V1.0
 Image Sensor OV9732 Output Format: MJPG, YVY2
 EFL 3.37 mm 30 FPS 1280 x 720 (Full HD)
 F.NO 2.8 30 FPS 640 x 480 (0.3MP VGA)
 Pixel 1280 x 720 30 FPS 176 x 144 (0.02MP)
 View Angle 67.4° Supporting OS
 Lens Type 1/4 inch Windows 7, 8.1, 10,Vista
 Lens Dimensions 8.50 x 8.50 x 4.87 mm Windows XP SP2 under UVC
 Module Size 30.50 x 28.50 mm Linux Kernel V2.6.2.1 or later
 Module Type Fixed Focus MAC OS 10.4 or later
 Interface USB 2.0 Operating Voltage: 5V +/- 5%
 IMT Lens Model IMT-1A6E001-6 Compliant with UVC Version 1.0
 Mating USB Cable KLT-USB1A-Cable 　




1/4" 5MP CSP F2.8 DFOV 67.4 Degree M6 InnoMaker Lens
IMT Model No.  IMT-1A6E001-6


  Lens Model IMT-1A6E001-6
  Sensor Format 1/4"
  Resolution 5 MP
  Sensor Type CSP
  Structure 4P + IR Filter
  Max Image Circle Ø4.8
  F/NO. 2.8 +/- 5%
  EFL (mm) 3.37
  TTL (mm) 4.15
  FOV Field of View
  Diagonal DFOV 67.4°
  Horizontal HFOV 56.3°
  Vertical VFOV 43.7°
  TV Distortion <1.5%
  CRA <26°
  Lens Filter 650nm +/- 10nm @50%
  Barrel M6*P0.35
