        5.14MP Sony IMX335 No Lens Camera Module
        Model No.  KLT-CMNL-IMX335 V1.0














The KLT-CMNL-IMX335 V1.0 camera module No Lens sensor board uses the Sony IMX335 high-quality image sensor, which has a diagonal of 6.52mm (1/2.8 type) CMOS image sensor, a pixel of 2.0μm, a color square pixel display, an effective pixel of 5 megapixels, and a high-definition image. When used with the master board, it can support 5MP pixel high-definition photography and 2K@30FPS video shooting. Connection to the master board either by directly plug or by coaxial cable for varies installation scenarios.  The PCBA board reserves a gyroscope spacing, supporting multi-axis EIS anti-shake image stabilization function. The board frame size is 32x32mm.



This camera module is not sold separately. The camera module is solely compatible our company’s Ai Master board as they must be sold in bundle, optionally with WiFi expansion board or Network Ethernet board.



 Specifications
 Model No. KLT-CMNL-IMX335 V1.0
 Image Sensor IMX335
 Image Sensor Type CMOS
 Effective Pixels 5.14 Megapixels
 Sensor Size 1/2.8"
 Pixel Size 2.0 um x 2.0 um
 EIS Anti-Shake (Reserved) Supportive Electronic EIS Image Stabilization
 Video Frame Rate 4K@30FPS/60FPS (Differential)
2.7K@30FPS
1080P@30FPS/60FPS
720P@60FPS/120FPS
 Photo Resolution
 (with Master Board)
20MP (5200x3900) (Differential)
13MP (4160x3120) (Differential)
12MP (4000x3000) (Differential)
10MP (3648x2736) (Differential)
8MP (3264x2448) (Differential)
5MP (2592x1944) Default
3MP (2048x1536)
2MP (1920x1080)
 Operating Temperature -10°C to +60°C
 Storage Temperature -20°C to +80°C
 Humidity 20% to 80%
 PCB Dimensions 32 x 32 mm
 PCB Screw Hole Spacing 28 x 28 mm
 PCB Screw Hole Diameter 2 mm
