| 8.51MP Sony IMX317 OIS MGS Fixed Focus USB 2.0 Camera Module |
| Model No. KLT-OIS-USB5A-FF-IMX317 V1.0 |
.jpg)
.jpg)
.jpg)
.jpg)
| Camera Module No. |
KLT-OIS-USB5A-FF-IMX317 V1.0 |
| Resolution |
8.51MP |
| Image Sensor |
IMX317 w/ MGS OIS |
| Sensor Type |
1/2.5" |
| Pixel Size |
1.62 um x 1.62 um |
| EFL |
3.57 mm |
| F.NO |
2.20 |
| Stabilization Method |
Optical Image Stabilization (OIS) |
| Stabilizer Type |
Micro Gimbal Stabilizer (MGS) |
| Stabilizer Axis No. |
2 Axis (Pitch and Yaw) |
| Stabilizer Angle |
Max. 3.0° |
| Stabilizer Power |
180 mW |
| Pixel |
3840 x 2160 |
| View Angle |
156.0°(DFOV) 126.0°(HFOV) 66.0°(VFOV) |
| Lens Dimensions |
19.00 x 19.00 x 25.20 mm |
| Module Type |
Fixed Focus |
| Auto Focus VCM Driver IC |
None |
| Interface |
USB 2.0 |
| Output Format |
MJPG |
| Auto Control |
Saturation, Contrast, Acutance
White Balance, Exposure |
| Audio |
None |
| Input Voltage |
DC 5V |
| Working Current |
Max 500mA |
| System Compatibility |
Windows XP (SP2, SP3), Vista, 7, 8, 10, 11
Android, Mac OS, Linux or OS with UVC Driver
Raspberry Pi by USB Port |
| Software for USB Camera |
AMCAP, Webcam Viewer, V4L2 Controls
Contacam, VLC Player, MotionEye OS
iSpy, ZoneMider, Yawcam |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-10°C to +70°C |
| USB Cable |
USB Cable |
|
