        8MP OmniVision OS08C10 MIPI Interface M12 Auto Focus Camera Module
        Model No.   KLT-MAB19-OS08C10 V1.0










 Camera Module No. KLT-MAB19-OS08C10 V1.0
 Resolution 8MP
 Image Sensor OS08C10
 Sensor Type 1/2.82"
 Pixel Size 1.449 um x 1.449 um
 EFL 3.24 mm
 F.NO 2.70
 Pixel 3872 x 2192
 View Angle 88.2°(DFOV)  80.2°(HFOV)  51.0°(VFOV)
 Lens Dimensions 18.00 x 18.00 x 23.82 mm
 Module Size 60.00 x 24.00 mm
 Module Type Auto Focus
 Interface MIPI
 Auto Focus VCM Driver IC DW9714P
 Lens Type 650nm IR Cut
 Operating Temperature -30°C to +85°C
 Mating Connector DF30FC-30DS-0.4V
